TLSAssistant

TLSAssistant is a modular extensive framework that combines state-of-the-art TLS analyzers with a report system that suggests appropriate mitigations and shows the full set of viable attacks. It is open-source, released under Apache-2.0 license and and you can contribute by visiting the project’s repository.

The tool has been developed within Digimat, a joint lab between Poligrafico e Zecca dello Stato and the Center for Cybersecurity of the Fondazione Bruno Kessler.

IPZS_logo

Architecture

current_architecture

TLSAssistant v2 is an evolution of the previous monolithic version: TLSAssistant v1.x

It currently integrates four tools:

To have a deeper understanding of the architecture, we must first grasp how it is organized.

TLSAssistant makes advantage of the idea of a “Module,” which is a collection of objects and classes that are joined in the same file by context (e.g., the type of vulnerability analyzed). Each module adheres to standards that must be followed in order to develop a compliant module.

We have different type of modules

  • Analysis Modules: modules that perform the analysis using independent code or external tools. This type of module will employ a submodule called wrapper to interface with external tools. The output module receives the Analysis module’s output.
    • Wrapper Modules: modules that wrap an external software or an API call. Given that output must be refined by the Analysis module, a wrapper should not be directly connected to the output module. Most of the time, the wrapper is an entire API of non-Python software.
  • Core Module: the modules’ router. It parses the specified configuration, runs each module, gathers the output and redirects it to the output module.
  • Output Module: formats the output properly by according to the mitigation standard and the provided information.

Defined standards

List of modules

Wrapper Modules

Module name Wraps
testssl.sh testssl.sh subprocess call
HSTS HTTPS API Call to check HSTS SET, Preloading and HTTPS Enforcement. Can be used to obtain information about the webserver.
tlsfuzzer tlsfuzzer script selection and call, following parameters and parsing output.
Certificate Subdomain enumeration by crt.sh API call. Useful for *.mysite.tld

Analysis Modules

Module Name Wrapper Used
3SHAKE testssl.sh
BEAST testssl.sh
BREACH testssl.sh
CCS Injection testssl.sh
Certificate Transparency testssl.sh
CRIME testssl.sh
DROWN testssl.sh
FREAK testssl.sh
HEARTBLEED testssl.sh
HSTS preloading HSTS HTTPS
HSTS set HSTS HTTPS
HTTPS enforced HSTS HTTPS
LOGJAM testssl.sh
Lucky13 testssl.sh
Mitzvah testssl.sh
NOMORE testssl.sh
Perfect Forward Secrecy testssl.sh
Poodle testssl.sh
Renegotiation testssl.sh
ROBOT testssl.sh
SLOTH tlsfuzzer
Sweet32 testssl.sh
TicketBleed testssl.sh

Wrapper Modules

Module Name Wraps
mallodroid Mallodroid python3 import and call.
SUPERAnalyzer SUPERAnalyzer subprocess call.

Analysis Modules

Module Name Wrapper Used
Accepting all SSL Certificates SUPERAnalyzer
Certificate or KeyStore Disclosure SUPERAnalyzer
Weak HostnameVerifier mallodroid
Obfuscated Code SUPERAnalyzer
SSL GetInsecure Method SUPERAnalyzer
SSL Error mallodroid
Weak TrustManager mallodroid
Weak Algorithms SUPERAnalyzer
WebView has SSL Errors SUPERAnalyzer
Module Name Type
Core Core
Stix Output
Configuration Core
Parse Input Configuration Core
Report Output

Flow

In this architecture, we have two different flow:

  • Flow of the end-user:

    To add a new Analysis module (see left of Architecture Figure), the developer must follow the provided standard. As a result, the new functionality will be detected and implemented by the Core module. In addition to providing the code for implementing the tests for identifying a vulnerability, if a mitigation is known, the developer should define it by producing a JSON file in accordance with the mitigation standards.

  • Flow of the developer:

    The end-user decides which modules to utilize in the analysis in Step 1 (see right of Architecture Figure) by supplying a configuration file or a command line list. Each configuration file is a context-specific collection of modules that conducts a certain kind of analysis (e.g., checking for vulnerabilities related to weak TLS ciphers). Step 2: The Core loads the configuration (if supplied) and the modules (from the list or configuration), ensuring that they are relevant to the kind of analysis requested.

Type of Analysis

Here a quick overview of the various types of analysis that may be requested:

  1. Single Host: Because the testssl.sh program covers the majority of the vulnerabilities assessed by the tool, we decided to make the analysis more efficient by doing a pre-analysis (Step 3a) to create a cache with its results. During current and future analysis, they will be utilized by each of the related testssl.sh modules (Step 3b), such as POODLE (an attack that uses the availability of SSLv3 to weaken the connection).
  2. Single APK: Each Android-related module, such as Unsecure TrustManager, performs the analysis (Step 3b) on the given APK.
  3. Multiple Hosts: On each of the domains supplied in an input list, we execute a Single Host analysis. Each result is concatenated and delivered as a single output to the Output module. The list can also be generated by subdomain enumeration.
  4. TLS Configuration and Fixes: If a configuration file is given, a WhiteBox analysis is conducted by loading the TLS configuration into memory and checking all accessible modules (Step 3b). Otherwise, if a configuration file and a valid hostname are given, a single host analysis is conducted, and the corrections are then merged into the provided TLS configuration. This is referred to as a Hybrid study since we run a BlackBox analysis on the hostname and then apply the changes to the configuration file.

Caching system

Each wrapper module includes a caching mechanism. Because it is unlikely that any value would change dramatically in a single runtime, the caching approach allows the program to be less invasive and more powerful (with a runtime usually less than a minute).

Pre-analysis (testssl.sh)

As stated before, a pre-analysis (step 3a) is required as a compromise between atomicity, efficiency, and execution speed. Because the testssl startup time is roughly 3 seconds, we need to limit the number of times the tool is called. To do this, the core will determine if the module being run is utilizing testssl.sh as a wrapper, and if so, it will get all testssl-related arguments. Following this, the core will fill the testssl wrapper cache, which will be executed once the analysis is complete.

Demo video

Related Publications

  • Matteo Rizzi, Salvatore Manfredi, Giada Sciarretta and Silvio Ranise
    Demo: TLSAssistant v2 - A Modular and Extensible Framework for Securing TLS
    In: Proceedings of the 27th ACM Symposium on Access Control Models and Technologies (SACMAT 2022) (DOI, news)
  • Matteo Rizzi, Salvatore Manfredi, Giada Sciarretta and Silvio Ranise
    A Modular and Extensible Framework for Securing TLS
    In: Proceedings of the Twelveth ACM Conference on Data and Application Security and Privacy (CODASPY 2022) (DOI, news)
  • Salvatore Manfredi, Mariano Ceccato, Giada Sciarretta, and Silvio Ranise
    Do Security Reports Meet Usability? - Lessons Learned from Using Actionable Mitigations for Patching TLS Misconfigurations
    In: The 16th International Conference on Availability, Reliability and Security (ARES 2021) (ETACS 2021) (DOI, complementary material, news)
  • Andrea Bisegna, Roberto Carbone, Mariano Ceccato, Salvatore Manfredi, Silvio Ranise, Giada Sciarretta, Alessandro Tomasi and Emanuele Viglianisi
    Automated Assistance to the Security Assessment of API for Financial Services in book Cyber-Physical Threat Intelligence for Critical Infrastructures Security: A Guide to Integrated Cyber-Physical Protection of Modern Critical Infrastructures
    In: Cyber-Physical Threat Intelligence for Critical Infrastructures Security: A Guide to Integrated Cyber-Physical Protection of Modern Critical Infrastructures (DOI)
  • Salvatore Manfredi, Silvio Ranise, Giada Sciarretta and Alessandro Tomasi
    TLSAssistant goes FINSEC: A Security Platform Integration Extending Threat Intelligence Language
    In: 1st International Workshop on Cyber-Physical Security for Critical Infrastructures Protection (CPS4CIP 2020)
  • Salvatore Manfredi, Silvio Ranise and Giada Sciarretta
    TLSAssistant: uno strumento per mitigare i problemi di sicurezza di TLS
    In: ICT Security Magazine (URL, news)
  • Salvatore Manfredi, Silvio Ranise and Giada Sciarretta
    Lost in TLS? No More! Assisted Deployment of Secure TLS Configurations
    In: Proceedings of the 33rd Annual IFIP WG 11.3 Conference on Data and Applications Security and Privacy (DBSec 2019), vol. 11559, pp. 201-220 (DOI, news)
